Model No: JW

DT Series Linear Weigher

Quantity :

Contact Now

The DT Series Linear Weigher is designed for precise quantitative weighing of fine powders and small uniform granules such as:
sugar, salt, seeds, rice, sesame, MSG, chicken essence, milk powder, coffee, and seasoning powder.
It is ideal for applications in the food, agriculture, chemical, and pharmaceutical industries.

Advanced Modular Control System – Equipped with a new-generation high-integration weighing module that ensures stable and accurate operation.
Automatic Vibration Adjustment – Automatically optimizes vibration amplitude for smoother feeding and easier setup.
Multi-Material Mixing Capability – Supports simultaneous weighing of multiple materials for mixed packaging solutions.
Real-time Parameter Adjustment – Parameters can be modified directly during production, ensuring flexible operation.
Stepless Vibration Feeding System – Ensures uniform material distribution and wider weighing ranges.

Model	JW-AX1	JW-AX2	JW-AXM2	JW-AX4	JW-AXS4
Identification Code	X1-2-1	X2-2-1	XM2-2-1	X4-2-1	XS4-2-1
Weighing Range	20–1000g	20–3000g	1000–12000g	20–2000g	2–300g
Accuracy	X(1)	X(1)	X(1)	X(1)	X(1)
Max. Weighing Speed	10–15 P/M	30 P/M	25 P/M	55 P/M	70 P/M
Hopper Volume	4.5L	4.5L	15L	3L	0.5L
Preset Programs	100	100	100	100	100
Max. Material Types	1	2	2	4	4
Operation Interface	7-inch Touch Screen	7-inch Touch Screen	7-inch Touch Screen	7-inch Touch Screen	7-inch Touch Screen
Optional Devices	Pattern Hopper / Collecting Hopper / Data Printer / Overweight Rejection Device
Power Supply	220V / 700–1200W / 50–60Hz / 5–6A
Packing Dimensions (mm)	860×570×920	920×800×890	1215×1160×1020	1080×1030×820	820×800×700
Net Weight	80kg	130kg	280kg	160kg	135kg
